For install instructions, please see the corresponding product description below.
$665.00
|
|||||||
| Item | Description | Qty | Part Number | ||||
| 1 | Spacer Body | 1 | 01-7012 | ||||
| 2 | “O” Ring (Cooling Water Passage) | 1 | 11-2014 | ||||
| 3 | “O” Ring (Oil Passage) | 1 | 11-4011 | ||||
| 4 | “O” Ring (Water Passage) | 1 | 11-2143 | ||||
| 5 | “O” Ring (Alignment Bushing) | 1 | 11-2228 | ||||
| 6 | 1 1/2″ Alignment Bushing | 1 | 01-2277 | ||||
| 7 | 7/16-20/14 x 3 1/2″ S/S Stud | 6 | 08-130904181 | ||||
| 8 | Washer 7/16″ AN S/S Thin | 6 | 08-160900001 | ||||
| 9 | Nut 7/16-20 Nylock S/S Thin | 6 | 08-090904001 | ||||
| 10 | 3 1/2″ Coupler | 1 | 01-2166 | ||||
| 11 | Loctite | 1 | 09-2038 | ||||
1 1/2″ SCX-SC Spacer for 2″ SC Lower
Kit Part # 01-8114
Installation Instructions: Click Here for PDF File
| Item | Description | Qty | Part Number |
| 1 | Spacer Body | 1 | 01-7012 |
| 2 | “O” Ring (Cooling Water Passage) | 1 | 11-2014 |
| 3 | “O” Ring (Oil Passage) | 1 | 11-4011 |
| 4 | “O” Ring (Water Passage) | 1 | 11-2143 |
| 5 | “O” Ring (Alignment Bushing) | 1 | 11-2228 |
| 6 | 1/2″ Alignment Bushing | 1 | 01-2277 |
| 7 | 7/16-20/14 x 3 1/2″ S/S Stud | 2 | 08-130904181 |
| 8 | 7/16-20/14 x 3 5/8″ S/S Stud | 4 | 08-13090418.51 |
| 9 | Washer 7/16″ AN S/S Thin | 6 | 08-160900001 |
| 10 | Nut 7/16-20 Nylock S/S Thin | 6 | 08-090904001 |
| 11 | 3 1/2″ Coupler | 1 | 01-2145 |
| 12 | Loctite | 1 | 09-2038 |
